Air pump DBMX200for gaselectricdiaphragm
Add to favorites
Compare this product
Characteristics
- Fluid
- air, for gas
- Operation
- electric
- Technology
- diaphragm
- Mobility
- stationary
- Domain
- industrial
- Applications
- service, outlet
- Voltage
- 230 V
- Other characteristics
- filter, linear, integrated
- Flow
Max.: 235 l/min
(62.08043 us gal/min)Min.: 160 l/min
(42.26753 us gal/min)- Pressure
Max.: 250 mbar
(3.626 psi)Min.: 100 mbar
(1.45 psi)- Power
230 W
(0.31 hp)- Fluid temperature
Max.: 40 °C
(104 °F)Min.: -10 °C
(14 °F)- Length
272 mm
(11 in)- Width
226 mm
(8.9 in)- Height
247 mm
(9.72 in)- Weight
12.8 kg
(28.22 lb)
Description
DBMX200
The DBMX200 is the 200 l/min linear diaphragm pump from the Airmac DBMX Series. It offers low noise with stable performance over the long lifespan of the pump. It is sold complete with a robust and sound reducing aluminium housing, integrated inlet filter, rubber feet, outlet port with additional rubber elbow connector and clamps, power cord and EU plug. To accomodate the increased performance when compared to the 80, 100 and 120 l/min DBMX pumps, the height of the housing is increased by 25mm.
› Flow rate of 200 l/mim against 200 mbar
› Low power consumption (230 W)
› Long life linear drive
› Safety switch to protect against diaphragm failure
› Fully serviceable (⇒ service kits)
Return to Linear Diaphragm Pump range.
