Type 2 surge arrester BRPI-2Lfor electrical installationsfor transient current protectionelectronic equipment
Add to favorites
Compare this product
Characteristics
- Type
- type 2
- Applications
- for electrical installations, for transient current protection, electronic equipment, electrical line, for data and telecommunication lines, anti-surge, for signal transmission, data center
- Other characteristics
- compact, gas discharge tube, modular, fast-response, DIN rail, plug-in, low-voltage, AC/DC, thermoplastic
- Voltage
6 V, 12 V, 24 V, 48 V, 60 V
- Primary current
5,000 A
Description
Place of Origin: China
Brand Name: BRITEC
Minimum Order Quantity: 100 Piece/Pieces
Packaging Details: Customized packaging
Delivery Time: shipped by 15-30 days after payment
Payment Terms: T/T
Supply Ability: 50000 Pieces per month
Features:
BRPI series of SPDs for data offers a range of product for general information.
The product can provide protection for two lines for general information.
With plug-in design, it is easy to replace the product during maintainace.
It has protection for 6V, 12V, 24V, 48V 60V and 180V
It offers 8/20us per-line 5kA protection.
The bandwidth can be 10Mbps and insertion loss ≤0.3dB.
Conform to IEC61643-21.
Catalogs
BRPI-2L
1 Pages
