Analog signal converter PXC-10

DIN railgalvanically-isolated

Signal converter for the conversion of an AC current signal to an analogue process signal. A typical application would be to convert a signal from a Current Transformator measuring high current to an analogue input of a PLC. Input, output and operating voltage are isolated to 3,75kV AC. Input range and output type and range are selected via choice of terminals - See wiring diagram. Features: • 0-1A AC and 0-5A AC input in one version. • Output 0-10VDC/2-10VDC/0-20/4-20mA - selected via terminals. • Output offset and gain adjustable ±5%. • LED indication of input less that 5% / i.e. indication of probe failure. • Galvanically isolation supply/input/output is 3,75kV AC 1 min. • Operating voltage 12-48V AC/DC, 115-230VAC.
