Safety relay MXV-20

voltageSPDTAC

Single phase voltage relay for detecting a level of AC or DC voltage. When the monitored voltage rises and reaches the determined setpoint, which is adjusted on the front panel, the relay energises. When the voltage drops and passes the setpoint, minus the hysteresis which is adjustable on the front, the relay de-energises. With inverted relay function the internal relay work the opposite way. The Voltage relay has a latch function where the relay after energising will remain energised, regardless of input voltage, until the latch jumper or the operating voltage is disconnected. Typically used in safety circuits. Features • Monitoring of 1-500VAC/DC in 4 ranges in one version. • Adjustable setpoint. • Adjustable hysteresis of 3-35%. • Automatic locking function (latch). • Inversion of the relay function. • Output SPDT. • Supply voltage 24VDC, 24VAC, 115VAC, 230VAC or 400VAC.
