Constant-current acceleration sensor AS-073
sensitivity

constant-current acceleration sensor
constant-current acceleration sensor
Add to favorites
Compare this product


Characteristics

Other characteristics
sensitivity, constant-current
Frequency

Max.: 10,000 Hz

Min.: 0.32 Hz

Description

Type: CCS Sensitivity: 100 mV/g Frequency range: 0,32 Hz… 10 kHz (± 3 dB) Min. Temp: -50 °C Max. Temp: +120 °C Hazardous area approval: no Accessory/ connection cable type: AO0572 (MIL-C 5015 – BNC), AO0573 (MIL-C 5015 – open endings) The AS-073 is mainly used formeasurement of vibrations at rotatingmachines such as turbines, pumps,compressors, etc. Measuring Principle The acceleration sensor operatesaccording to the piezoelectricRingshear principle. In the sensor thepiezo element and an internal massforms a spring-mass damping system When this system is subjected tovibrations, an electrical chargeproportional to the vibrationacceleration is produced. An integrated amplifier converts thischarge signal into a usable voltagesignal.

Catalogs

No catalogs are available for this product.

See all of Brüel & Kjær Vibro‘s catalogs
