3-axis CNC milling machine PFU 1510

universalbridgefor aluminum

Drive: optional stepper motor or servo motor Programmable resolution: 0.0025 mm Repeatability: about + / - 0.02 mm Maximum Backlash: 0.04 mm (using software adjustable to 0.000 mm) Linear guidings: Bosch Rexroth Linear guidings Y-axis 25 mm, X-and Z-axis 15 mm grinded and with hardened surface Spindles: 16 mm ballscrews X-axis: Aluminium 100 mm x 100mm Reference switch on all axes Clamping area: ca. X = 1000 mm x Y = 1500 mm Processing area: X = ca. 1020 mm Y = 1470 mm and Z = 135 mm Working area: X = ca. 1000 mm Y = 1480 mm Passing height under Portal: ca. 150 mm Passing height under Z-axis: ca. 150 mm Overall dimensions with motors: LxWxH = ca. 1800 x 1600 x 1600 mm Weight: 480kg Power Supply: 230 V / 50 Hz
