Power supply DT5470

Single Desktop HV channel powered and controlled by USB 5 kV / 200 µA output range Available with positive or negative polarity SHV output connector Low Ripple Under/over-voltage alert, overcurrent and max. voltage protection Interlock logic for board enable and Individual channel kill 4 nA Current monitor resolution (with x10 Imon Zoom: 400 pA) Software Tools for easy channel management Overview The DT5470 is a desktop module housing one High Voltage Power Supply Channels 5 kV / 200 µA. The unit is available with either positive or negative output polarity; it is supplied via USB link. HV output is delivered through SHV connector. The HV output Ramp-up and Ramp-down rates may be selected independently for each channel in the 1 ÷ 500 V/s range with 1 V/s steps. The module features 4 nA Iset/Imon resolution. Zoom (x 10) for Imon increases resolution to 400pA. Functional parameters can be programmed and monitored via USB. Software available (Windows): LabVIEW Instrument Driver DT547x Control software: LabVIEW Control software with Logging Capability. DT547x Control software allows to set and monitor, through a Graphical User Interface, all the unit’s functional parameters. When DT547x Control Software runs, it creates a data-log file that records the changes of the monitoring parameters.
