I/O power supply module N1410

4 independent channels in 1U NIM module 1 kV / 200 µA output range Channels with individually selectable positive or negative polarity SHV output connectors Common floating return Low Ripple Under/over-voltage alert, overcurrent and max. voltage protection Interlock logic for board enable and Individual channel kill 5 nA Current monitor resolution (with x10 Imon-Zoom: 500 pA) Graphic color display Local and Remote control (USB2.0/RS485/RS232) Daisy-chain capabilty Optional DC Input Power Equalizer Software Tools for easy channel management Overview The Mod. N1410 provides 4 independent High Voltage channels in a single width NIM mechanics. Each channel can provide a ±1kV max voltage, a 200µA max current . The output polarity is independently selectable for each channel. Channels have common floating return (common return insulated from the crate ground); HV outputs are delivered through SHV connectors. The HV output Ramp-up and Ramp-down rates may be selected independently for each channel in the range 1÷100 V/s in 1 V/s steps.The module features 5 nA Iset/Imon resolution. Features include Imon Zoom, increasing resolution to 500 pA. Power supply control can be performed either locally, assisted by a Graphic color display or remotely, via USB, RS232 or RS485, the latter allowing to build a daisy chain network of modules N14XX. It is also controllable via TCP/IP by the Smart Fan Unit of CAEN NIM8301. A complete set of free software Tools is available to control this unit: GECO2020 with user friendly GUI and CAEN HV Wrapper library for custom SW development. EPICS and LabVIEW also supported
