Stainless steel solenoid valve - CFB series - CAMOZZI AUTOMATION

Characteristics

Control

direct-acting

Ports/positions

3-way

Function

Medium

for water, for gas

Body

compact, stainless steel, IP65

Other characteristics

for aggressive media, plug

DN

Max.: 4 mm
(0.157 in)

Min.: 1.5 mm
(0.059 in)

Voltage

Max.: 230 V

Min.: 12 V

Temperature

Max.: 140 °C
(284 °F)

Min.: -10 °C
(14 °F)

Pressure

Max.: 25 bar
(362.6 psi)

Min.: 0 bar
(0 psi)

Description

» Stainless steel version for particularly aggressive environment and fluids » High reliability over time, even in hard working conditions » Compact dimensions » Suitable to control inert and medical gases, alimentary fluids and beverages Series CFB Stainless Steel direct acting solenoid valves for general purpose, 2/2-way and 3/2-way NC, are the ideal solution for a wide range of applications whereby the environment and fluids used can be particularly aggressive and contaminating. Special versions are available on demand. The valve function is determined by a poppet and the operation is direct. Different versions are available according to the nominal diameter and to the threaded ports, as shown in the following tables. They can thus satisfy various requirements in terms of flow rates and working pressures.
