Ball check valve VNV series
male-femaleshut-offaluminum

Ball check valve - VNV series - CAMOZZI AUTOMATION - male-female / shut-off / aluminum
Ball check valve - VNV series - CAMOZZI AUTOMATION - male-female / shut-off / aluminum
Ball check valve - VNV series - CAMOZZI AUTOMATION - male-female / shut-off / aluminum - image - 2
Ball check valve - VNV series - CAMOZZI AUTOMATION - male-female / shut-off / aluminum - image - 3
Add to favorites
Compare this product


Characteristics

Type
ball
Body
male-female
Applications
shut-off
Material
aluminum
Flow rate

Min.: 38.3 l/min
(10.12 us gal/min)

Max.: 616.7 l/min
(162.91 us gal/min)

Description

These check valves are mainly used on vacuum gripper systems containing multiple suction pads in order to shut off individual suction pads which are not covered. Thread size M5, G1/8, G1/4, G3/8, G1/2. Applications: - For applications in which all suction pads are not always occupied (deactivation of the individual suction cups if they are not occupied, the system vacuum remains). - Handling pieces of different shapes and sizes with the same gripping system. Description - - ball seat valve with fixed bypass function - aluminium body with internal elements in brass - integrated dirt filter
