Pneumatic cylinder 41 series
magnetic pistontie-roddouble-acting

Pneumatic cylinder - 41 series - CAMOZZI AUTOMATION - magnetic piston / tie-rod / double-acting
Pneumatic cylinder - 41 series - CAMOZZI AUTOMATION - magnetic piston / tie-rod / double-acting
Pneumatic cylinder - 41 series - CAMOZZI AUTOMATION - magnetic piston / tie-rod / double-acting - image - 2
Pneumatic cylinder - 41 series - CAMOZZI AUTOMATION - magnetic piston / tie-rod / double-acting - image - 3
Add to favorites
Compare this product

Characteristics

Type
pneumatic
Technology
magnetic piston, tie-rod
Configuration
double-acting
Material
stainless steel, anodized aluminum
Norms
ISO 15552
Other characteristics
standard, with adjustable cushions
Stroke

Max.: 2,500 mm
(98.425 in)

Min.: 10 mm
(0.394 in)

Pressure

Max.: 10 bar
(145 psi)

Min.: 1 bar
(14.5 psi)

Speed

Max.: 500 mm/s
(1.64 ft/s)

Min.: 10 mm/s

Ambient temperature

Max.: 80 °C
(176 °F)

Min.: 0 °C
(32 °F)

Description

» In compliance with ISO 15552 standard and with the previous DIN/ISO 6431/ VDMA 24562 standard » Rolled stainless steel rod » Adjustable pneumatic cushioning » Rod scraper in brass » ATEX Series 41K cylinder comply with the ISO 15552 standard and can be assembled with the entire range of standard accessories. The mounting brackets used on the end-blocks tube are designed in an extremely secure way, making use of cylinder tie-rods positioned internally and not visible on the assembled cylinder. This cylinder series is normally equipped with adjustable endstroke cushioning by means of a screw positioned on the end-block. Materials - AL end blocks and piston - rolled AISI 420B stainless steel piston rod - zinc-plated steel piston rod nut - anodized AL-profile tube zinc-plated steel tie-rods and tie-rod nuts - NBR-PU rod - piston - cushion seals - brass rod scraper Mounting - with front flange - rear flange - foot mounts - centre trunnion - front and rear trunnion Fluid - filtered air, without lubrication. If lubricated air is used, it is recommended to use oil ISOVG32. Once applied the lubrication should never be interrupted
