Wire EDM software

programmingfor CNC machinescutting

World’s Most Advanced Wire EDM Programming Take your Wire EDM programming to the next level with CAMWorks Wire EDM – increasing efficiency and reducing delivery times. With CAMWorks Wire EDM, you can go from solid model to G-Code in ONE Click! Once the solid model is opened, the user clicks on the Solid to G-Code button and the system automatically: • Searches the part for machinable features • Identifies features • Generates the operations • Applies users’ preferences and settings such as wire offsets, cutting conditions, and start holes • Creates toolpaths • Posts the G-Code Cutting-Edge Wire EDM Processing Fully integrated into SOLIDWORKS, CAMWorks Wire EDM provides a more intuitive and efficient method of generating EDM toolpaths and machine code. CAMWorks Wire EDM software has been designed and developed specifically for programming 2-axis through 4-axis Wire EDM CNC machines using feature-based technology, including automatic feature recognition and knowledge-based machining, to automate the Wire EDM programming process. CAMWorks Wire EDM is available in Wire EDM Professional and Wire EDM Premium levels. Automatic and Interactive Feature Recognition • 2-axis and 4-axis Wire EDM features are automatically recognized on solid part models • Features can also be defined interactively by the user • Create 2-axis and 4-axis In (Die/pocket) features, Outside (Punch/boss) features, and Open Profile features • Automatic start hole recognition using sketched circles or points • Sub-program support for patterned features
