Air heater CAST-X 2500

circulationstainless steelexplosion-proof

APPLICATIONS: Natural Gas Regeneration & Fuel Conditioning Paint, Solvent & Petrochem Heating For Use in Temperature Control Units (TCUs) Beverage Processing & Pasteurization Industrial Gas Heating & Air Separation Urethane / Foam System Heating FEATURES & BENEFITS: Fluid Path has No Contact with Heating Elements Heated Media is Isolated in Seamless 316 Stainless Steel Tubes Allows for Safe Heating of Explosive Gases & Flammable Liquids Excellent Performance in High-Pressure Applications Suitable for Use with Sterile and Zero Contaminant Processes Compatible with Standard Controls (PID, PLC, Multi-Loop, etc.) Small Size Enables Easy Integration into Larger Machines Self-Draining Flow-Tubes, and Long-Life Heating Elements SPECIFICATIONS: Power: 2.5 kW Total to 15 kW Total Voltage Range: 208 - 575V Max Line Current: 30 A per circuit Tubing: .625” OD (5/8") (15.9 mm) .065” Wall (1.7 mm) Overall Process Tube Length: 130” (3302 mm) each 316L Stainless Steel (standard) Inconel (optional upgrade) Passivated or Electro-Polished (optional upgrades) Max Pressure: 4000 psi (275 bar) Enclosures: NEMA 1 (general-purpose/dust-proof) NEMA 4 (moisture-resistant) NEMA 7 (explosion-proof) ATEX (explosion-proof) Max Working Temperatures: NEMA 1 (dust-proof/general-purpose): 662°F (350°C) NEMA 4 (moisture-resistant): 572°F (300°C) NEMA 7 (explosion-proof): 482°F (250°C) ATEX (explosion-proof): 482°F (250°C) Published temperatures are for housing at 12 o’clock position; Higher temps may be possible at 6 o’clock position. See factory for details.
