Current transformer SSR-31 seriesencapsulatedindustrialDIN rail mount
Add to favorites
Compare this product
Characteristics
- Type
- current
- Configuration
- encapsulated
- Applications
- industrial
- Mounting
- DIN rail mount
- Other characteristics
- summation
- Output power kVA
0.015 kVA
(0.020394 hp)- Secondary voltage
720 V
- Secondary current
1 A, 5 A
- Frequency
50 Hz, 60 Hz
Description
Electrical properties
Test insulation voltage
4 kV, 1 min.
Rated short-time thermal current (Ith)
60 x IN
Dynamic rated current (dyn)
2.5 x Ith
Self-consumption
Max. 4 VA
Installation class
E
Mechanical properties
Housing
Made of self-extinguishing ABS UL94 V-0
Degree of protection
IP40
Mounting
DIN rail DIN EN50022 or screw mounting
Connections
Nickel plated with plus-minus screws
Degree of protection of the terminals
IP 10, with terminal cover = IP20 (option)
Max. Ratio for unequal main transducers
1:10
