Water rotary joint QCN0201-85-08P-04S-02EG

for gasfor air2-passage

CENO air rotary union can pass compress air, nitrogen and so on. The rotary union contains two precise bearings, they share a smooth and lasting high-speed running with firmness and flexibility. With many advantages long life, rapid delivery, transmit100M/1000M Ethernet, integrate various signal, anti-interference. Pneumatic, hydraulic channel are all able to use connector to do connection, convenient to on-site installation. • Current : 8*30A;4*2A;2 group Driver-cliq Ethernet encoder signal • Voltage : 380VAC/VDC • Insulation resistance : ≥500MΩ@500VDC(current) ≥100MΩ@100VDC(signal) • Dielectric strength : - ≥1500V@50hz(current) ≥500 V@50hz(signal) • Resistance fluctuation : ≤10mΩ(with50rpm) • Contact Material : Precious Metals • Operating temperature : -20℃~+60℃ • Channel number : 2 • Connector size : G1/8
