Water rotary joint QCN0102-03P

for oilfor compressed airfor gas

The gas-liquid rotary joint is used specially transmitting gas and liquid media, mainly including compressed air, hydrogen, nitrogen, water, oil, coolant and so on. Light weight, compact size, one air flow passage rotary union with aluminum alloy construction, interface G1/4'', rotor side is fixed by flange, stator side is fixed by anti-rotation tab.Typical application including automatic equipment, machinery manufacturing, food processing etc. Any special requirements, pelase conatct with us, we will provide the best solution for you. • Current : 3*25A • Voltage : 0~380VAC/VDC • Electrical noise : ≤10mΩ(50rpm) • Dielectric strength : ≥1500V@50Hz • Insulation resistance : ≥500MΩ@500VDC • Contact material : Precious metals • Housing material : Aluminum alloy,stainless steel • Air channel : 1 channel*water (G1/4’’) • Pressure : ≤4MPa
