Description
MULTICETA SYSTEM OVERHANGING PLATFORMS AND LOADING TOWERS
Overhanging loading platforms are composed of CK 33 x 180 deck panels and 5 cm-thick wooden planks supported by 180 cm-long cross beams. When there is no need to reduce ground space occupation and high load capacities are required, modular loading towers are used.
LOADING PLATFORMS
MaterialS235JR steel
FinishHot-dip galvanised coating in accordance with UNI EN ISO 1461
WeldingIn accordance with regulations UNI EN ISO 15607 and UNI EN 1418
Cross-beam length180 cm
CK deck panels33 cm x 180 cm
Simple platform size180 cm x 180/250 cm
Composite platform size180 cm x 360/500 cm
Load capacity450 kg/m2
LOADING TOWER
MaterialAcciaio S235JR
FinishHot-dip galvanised coating in accordance with UNI EN ISO 1461
WeldingIn accordance with regulations UNI EN ISO 15607 and UNI EN 1418
Cross-beam length250 / 300 cm
