Roadheader Sandvik MR620

Tunnelling and mining The Sandvik MR620 is an electrically powered and crawler-mounted roadheader that is engineered to excavate roadways and galleries. This heavy-duty machine has a powerful transversal cutter head mounted on an extremely robust telescopic boom. It is designed to excavate rock with high compressive strengths. The MR620 is available as PLC (Programmable Logical Controlled) or hydraulically controlled machine. According to country regulations the machines can be delivered with FLP (flameproof) certifications from various international approval authorities. Designed for economical excavation of rock exceeding 120 MPa uniaxial compressive strength to minimize operating costs. Hydraulically stabilized telescopic cutter boom offers optimum cutting power. Spraying systems efficiently suppress dust and cool cutting tools. Total weight approx. - 118,000 kg Dimension (length;width;height) - 15520 x 4800 x 2400 mm Cutting height (maximum.) - 5900 mm Cutting height (minimum.) - 3500 mm Cutting width - 5500 - 8900 mm Cutter motor - 300 kW Ground pressure - 0.18 MPa Loading capacity - 350 m³/h Conveying system, chain speed - 3.5 m/min Total installed electric motor power - 540 kW Volltage (standard) - 10.00V Cutter head speed - 1.4 m/s
