CW laser module S-GDL-532

solid-stategreendiode

S-GDL 532nm is the smallest green laser module in the world Features: Ultra compact Low cost Specifications: Wavelength (nm) 532±1 Output power (mW) >1 >5 >20 >50 >80 >100 LD operating current (mA) 400 400 500 600 600 600 700 Transverse mode TEM00 Operating mode CW M2 factor <1. 2 Beam divergence, full angle (mrad) 85% power stability (rms) <10% , over 4 hours at constant temperature after warm up <20%, over operating temperature range Beam alignment tolerance Position (△r) <0. 3mm Angle (mrad) <15mrad LD operating voltage (v) <2. 0 Operating lifetime (hours) 5000 Residual IR <0. 2% Operating temperature (℃) 10~35 Operating humidity 5%~95% Storage temperature (℃) -40~85 Package size（mm） ф12×13 Warranty 6 months Remark: If smaller divergence is needed, PGL-VI is available Applications: Laser module assembling Laser scanning Laser alignment Surveying equipments Laser display
