Resistance welding system DW 200P

automaticbenchtopfor electronic components

Precision Spot Welding Machine DW200P DW-200P is a high-precision desktop visual resistance welding system, which can realize real-time pressure inspection to give an alarm when the parameter range threshold is exceeded, precisely control the pressure and energy, and improve the quality control capability. Yield Improvement Real-time welding pressure inspection to give an alarm when the preset range is exceeded. Precise energy control to effectively prevent burns around the pad. Precise pressure control to effectively prevent the pad from collapsing. Suitable for Automated Production Line The head and power supply combination occupies a small space and is light-weight. It supports communication with the MES system, and can be flexibly integrated in the automated production line. Poor Welding Insufficient energy or pressure. Pad Collapsing Too high pressure. Substrate Warpage and Peripheral Burns Excessive energy caused by too high pressure and too long contact time. High-Precision Energy Control Closed-loop energy control to quickly achieve stable output and effectively prevent the pad burns caused by energy diffusion. High-Precision Pressure Control Closed-loop pressure control with the error of ±5g, and real-time pressure inspection to give an alarm when the threshold is exceeded.
