Voltage tester CA 6116N

insulation resistance and continuityresistancephase sequence

Highlights - 32 direct command keys, "Windows-like" menus and graphical commands on 5.7-inch touch screen. - 4 channels isolated from one another and in relation to the earth on reinforced plastic BNC - connectors, in replacement of the METRIX OX 822,OX 842 and OX 862 mixed differential oscilloscopes. - 2.5 GS/s sampling rate in one-shot mode and 1 GS/s in repetitive mode - Resolution: 12 bits - "Real-time" FFT analysis, simple and complex calculation functions on the channels over 2,5 pts - TRMS, 8,-count, 2 kHz digital multimeters with time/date-stamped graphical recording on all 4 channels Description The C.A 6116N is an ALL-IN-ONE instrument for testing electrical installations in compliance with the national and international standards (IEC 60364-6, NF C 15-100, VDE 100, FD C 16-600, etc). It combines design, ergonomics, simplicity, performance, rapidity and accuracy. Suitable for all neutral systems (TT, TN, IT), it is ideal for all sectors: industry, tertiary and residential. Ergonomics The rugged, compact C.A 6113 is specially designed for quick and effective familiarization. large LCD graphic colour display with backlighting, users can view all the crucial results at a glance. A rotary switch on the instrument’s front panel gives direct access to all the functions. A large number of visual symbols and audio signals help with quick interpretation of the results in accordance with the standards. The on-line contextual help menus can guide the user step by step, if needed. The storage capacity can save up to 1,000 tests. The C.A 6116N also has a USB output for data transfer.
