Continuous bioreactor Plantrix® MR555

processpilotmodular

Plantrix MR555 is a modular, ceramic Flow Reactor for pilot & full-scale production. Fabricated from diffusion bonded 3MTM silicon carbide, with integrated heat exchange, Plantrix modules give unrivalled chemical compatibility & process control for challenging chemical applications at scale. Employing standard compression fittings, Plantrix can be used with existing pumps & thermostats, or supplied as total systems on request. Examples of User applications: •Fast, strongly exothermic reactions •Reactions with aggressive media & / or unstable intermediates •Material supply under GMP conditions •Processes include nitrations, cyanations, lithiations, diazotisations & halogenations •Flow rate: 80-6667 ml/min (up to 400 kg/h) •Reactor volume: 100 up to 4000 ml •Wetted materials: SiC, PTFE & FFKM •Dimensions: 346 (W) x 823 (D) x 1421 mm (H)
