RS485 transceiver XC485ET

half-duplex

XC485ET is a RS-485 transceiver with 5V power supply, integrated TVS protection tube, with enhanced ESD protection, includes one driver and one Receptor. Fail-safe circuitry is inside the chip, when the Receptor inputs are open or shorted to ensure that Receptor output logic high level. If all drives hooked on the terminal matching bus are disabled (high impedance), the Receptor will output logic high. It can be mounted up to 256 transceivers on the bus. A, B are built in XC485ET respectively to TVS protective tube of GND. Features: Internal TVS protective tube（A、B respectively to GND） 5V Operating Voltage RS-485 I/0 Pin with enhanced ESD protection ±15kV，human body discharge mode ±8kV IEC61000-4-2，Contact discharge ±15kV IEC61000-4-2，Air discharge Real fail-safe circuitry receptor Up to 256 transceivers can be hooked on the bus Standard 8 pins, SOP Temperature: -40℃~85℃（Industry standard） Supports half-duplex communication Applications: Electricity meter, water meter, gas meter Industry Control Security Systems Lighting System
