Plunger pump LSWP serieswatergasoline engineindustrial
Add to favorites
Compare this product
Characteristics
- Technology
- plunger
- Fluid
- water
- Operation
- gasoline engine
- Domain
- industrial
- Flow
30 m³/h, 60 m³/h, 100 m³/h
(1,059.44 ft³/h, 2,118.88 ft³/h, 3,531.46667 ft³/h)
Description
PARAMETERS
Model
LSWP20
LSWP30
LSWP40
Inlet & Outlet Inside Dia (mm)
50 (2 inch)
80 (3 inch)
100 (4 inch)
Pump Lift (m)
23
28
20
Suction Height (m)
7
7
7
Max. Capacity (m³/h)
30
60
100
Engine
LS196
LS208
LS420
Dimension (L*W*H)(mm)
500*395*445
550*395*475
690*505*585
Net Weight (kg)
26
29
48
