Type 2 surge protector NSB-10/230-C4-WW-IP
type 3class IIclass III

Type 2 surge protector - NSB-10/230-C4-WW-IP - Cirprotec - type 3 / class II / class III
Type 2 surge protector - NSB-10/230-C4-WW-IP - Cirprotec - type 3 / class II / class III
Type 2 surge protector - NSB-10/230-C4-WW-IP - Cirprotec - type 3 / class II / class III - image - 2
Add to favorites
Compare this product

Go to the Cirprotec website for more information

Characteristics

Type
type 2, class II, type 3, class III
Applications
for telecom applications, outdoor, for LED lighting
Other characteristics
compact, combined, in-line
Voltage

230 V

Primary current

5,000 A

Description

NSB is the range of devices for discharging transient overvoltages (Type 2+3 / Class II+III). In-line format, compact and with different conection options. Features • Combined discharge voltaje (1,2/50) until 10 kV. • Universal, solutions for class I and class II LED. • Visual end of life indication LED + disconnection. • Compact and easy to install in any luminaire. • Type of conection: Wire in - Wire out. • The major manufacturers of outdoor LED luminaires install NS into their streetlights (OEM). • Specific enclosure requirements IP66. Standards and certifications • IEC 61643-11 • EN 61643-11 Applications • Building • Industry • Outdoor LED Lighting • Telecom • Water treatment
