Pneumatic fitting PE LINEtappedpush-inelbow
Add to favorites
Compare this product
Characteristics
- Applications
- pneumatic
- Attachment
- tapped, push-in
- Configuration
- elbow, T
- Material
- NBR, nickel-plated brass
- Gender
- male, female
- Diameter
Max.: 12 mm
(0.472 in)Min.: 0.25 mm
(0.01 in)- Operating pressure
20 bar
(290.08 psi)
Description
Push-in fittings featured by the so called "easyThread" and made according to Cmatic Standards. This thread feature allows for connections with different threads standards (NPT, BSPP, BSPT) and leads to greater operational flexibility and inventory cost reduction.
1-2 > Body and Release Ring: Brass UNI EN 12164 CW614N - UNI EN 12165 CW617N Nickel Plated 3 > Holding Ring: Acetal Resin (POM) 4 > Gripping collet: Stainless steel AISI 301 5 > Protection Ring: Acetal Resin (POM) 6 > Seals: NBR
Recommended tubings: PA11, PA12, PA6, Polyethylene PE, Polyurethane PU (98 Shore A).
Acceptable Tolerances on the tubings: +/– 0,07 mm up to Ø 3/8” - 10 mm +/– 0,1 mm Ø 1/2” - 12 mm.
Application fields: Pneumatic circuits.
