Pneumatic fitting MF Line
threadedpush-inelbow

Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow
Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow
Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow - image - 2
Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow - image - 3
Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow - image - 4
Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow - image - 5
Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow - image - 6
Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow - image - 7
Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow - image - 8
Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow - image - 9
Pneumatic fitting - MF Line - C.Matic S.p.A. - threaded / push-in / elbow - image - 10
Add to favorites
Compare this product


Characteristics

Applications
pneumatic
Attachment
threaded, push-in
Configuration
elbow, T
Material
brass
Gender
male, female, male-female, female-female, male-male
Other characteristics
for the food industry, wide temperature range, automatic, all-fluid
Diameter

Min.: 4 mm
(0.157 in)

Max.: 8 mm
(0.315 in)

Operating pressure

20 bar
(290.08 psi)

Description

MF is a push-in fitting line designed and certified for Food and Beverage applications. MF fittings are made of brass with low lead content and it is NSF certified according to the 169 standards for contact with water, tea, and coffee. MF is C.matic’s brand new push-to-connect fitting designed and certified for Food and Beverage applications. C.matic’s MF fitting is made of brass with low lead content and it is NSF certified according to the 169 standards for contact with water, tea and coffee. This makes C.matic’s MF fitting The Right Solution for the coffee and vending machines industry. On top of the 169 NSF/ANSI Certificate, the MF fitting boasts also the NSF/ANSI 372 brass compliance with the maximum lead content standards allowed for contact with drinking water (U.S. Safe Drinking Water Act). 1 > Body: Brass EN12164 CW510L Compliant NSF/ANSI 372 FDA Compliant FPM 2 > Gripping collet: Brass EN12164 CW510L Compliant NSF/ANSI 372 FDA Compliant FPM 6 > Seals: FDA Compliant FPM
