Pneumatic fitting PM Line

threadedpush-inelbow

The push-in fittings of the PM line are manufactured according to the American Standards (inch Tubings and NPT threads). They are conceived to work up to 1,160 psi in central grease applications. The push-in fittings of the PM line are manufactured according to the American Standards (inch Tubings and NPT threads). They are conceived to work up to 80 bar in central grease applications. 1 > Body: Brass UNI EN 12164 CW614N - UNI EN 12165 CW617N Nickel Plated 2 > Gripping collet: Brass UNI EN 12164 CW614N Nickel Plated 3 > Seals: NBR Recommended tubings: PA6-6, PA12 HR Acceptable Tolerances on the tubings: +/– 0,07 mm up to Ø 1/4. Application fields: Lubrication installations.
