Pneumatic fitting AR Linepush-inelbowPOM
Add to favorites
Compare this product
Characteristics
- Applications
- pneumatic
- Attachment
- push-in
- Configuration
- elbow
- Material
- POM, NBR, nickel-plated brass, steel
- Gender
- male
- Other characteristics
- 360° adjustable, with ball bearing
- Diameter
Max.: 12 mm
(0.472 in)Min.: 4 mm
(0.157 in)- Operating pressure
18 bar
(261.07 psi)
Description
Rotary push-in fittings suitable for applications with rotating and swinging movements.
Push-in fittings featured by a special protection release ring against materials deposits (dust, and processing residues), which if inside of the fitting, could jeopardize the correct fitting function and the tubing disconnection. The presence of an o-ring between the release ring and the tubing prevents dirt from falling in.
1-2 > Body and Release Ring: Brass UNI EN 12164 CW614N - UNI EN 12165 CW617N Nickel Plated 3 > Holding Ring: Acetal Resin (POM) 4 > Gripping collet: Stainless steel AISI 301 5 > Protection Ring: Acetal Resin (POM) 6 > Seals: NBR 7 > Ball bearing: Steel
Recommended tubings: Polyurethane (PU); rigid tubings are not recommended.
Application fields: Pneumatic circuits.
Catalogs
AR LINE
4 Pages
Exhibitions
Meet this supplier at the following exhibition(s):
