Automatic slitting machine E4-300B

Fully automatic nonstop working cycle, including the overturning of the turret with manual loading and unloading of material. Max. working width:1700mm. (67”). Max. outside Ø of log: 300mm (11,8”) on Ø 76mm (3”) mandrels with Ø400mm (15,8”) blades. Max. weight of material loadable on unsupported mandrel: 80 kg (176.5 lbs); with supported mandrel , 200 kg (441lbs). N. 4 Interchangeable mandrels from Ø 51mm (2”) to Ø 76mm (3”). Indexing tolerance: +/- 0,1mm (0,003”). Cutting width: from 2 mm (0,008”). with decimal increasing. Cutting system: two over imposed circular blades to slit two logs simultaneously on two mandrels, with other two are available for loading/unloading operation. Turret rotation combined with pneumatic chucks with plateau to provide continuous operation and allows faster loading and unloading of material. N. 4 pneumatic jaws chucks with plateau Ø 300mm (11,8”). Driven blade unit. Automatic blade pivoting angle. Automatic detection of log diameter on the upper log. Machine controlled by “PLC SIEMENS” and interface operator “TP700” colour touch screen technology This model can be customized to meet customer's needs thanks to a wide range of options available.
