Rotary drilling rig GEO 205
Add to favorites
Compare this product
Characteristics
- Drilling unit
- rotary
- Machine weight
2,400 kg, 2,800 kg
(5,291.1 lb, 6,172.9 lb)- Motor power
33 kW
(44.87 hp)
Description
Max Width - 750 - 1.150 mm - 2.5 - 3.8 ft
Mast Feed - 1.030 - 2.800 mm - 3.4 - 9.2 ft
Feed Force - 2.500 daN - 5,620 lbs
Retract Force - 2.500 daN - 5,620 lbs
Rotary Torque - 200 - 480 daNm - 1,475 - 3,540 lb*ft
Rotary Speed Range - 80 - 580 rpm
Clamp Range - 45 - 220 mm - 1.8 - 8.7 in
