Rotary ring stretch wrapper RONDA OMEGAautomaticpalletwith conveyor
Add to favorites
Compare this product
Characteristics
- Type
- rotary ring
- Operating mode
- automatic
- Product applications
- pallet
- Other characteristics
- with conveyor, double-roll
- Height
4,325 mm
(170 in)- Width
3,825 mm, 3,900 mm
(151 in, 154 in)- Length
4,000 mm, 4,200 mm
(157 in, 165 in)- Maximum wrapping height
2,200 mm
(86.61 in)- Maximum pallet length
Min.: 600 mm
(23.62 in)Max.: 1,300 mm
(51.18 in)- Maximum pallet width
Min.: 800 mm
(31.5 in)Max.: 1,200 mm
(47.24 in)- Rotational speed
65 rpm, 70 rpm
(408 rad.min-1, 440 rad.min-1)- Voltage
400 V
- Power
12 kW, 13 kW
(16.32 hp, 17.68 hp)- Capacity
140 p/h
Description
The only machine with external pre-stretch drive system, without electric sliding contacts/slip rings or other complex and expensive solutions like electric generator. Available for output capacity up to 140 pallet /h. Also available with double reels.
TECHNICAL CHARACTERISTICS
> System & motors IP 54
> Operating pressure 6 bar
> Pre-stretch ratio Min. 160% -Max. 300%
Roping System: Reducing the film width to form a rope to ensure more effective load stabilisation.
Film cut, clamp and weld unit self adjusting for any size of pallet.
Automatic system for controlling belt rotation tension of the ring with alarms displayed on Display.
Pallet holding presser without travel limitation (optional).
Catalogs
RONDA OMEGA
2 Pages
