Gummed paper case sealer GEM X670 GP - BX 670 GP

multi-flapadhesive tapeautomatic

GEM X670-GP - Lateral side drive belts H50mm - Drive belts speed adjustable - Motor start / stop for energy saving - Box size adjustment automatically: box height adjustment by Brushless motor (fig. 2) - Box size adjustment in width: pneumatically - Box height detection, to be defined : with a tester (fig. 3), DCM application, box menu, either other on demand, for the top sealing unit positioning - Top & Bottom taping head with autonomous water tank with adjustable humidification (fig. 1) - Gummed paper tape application of normal, fibber and reinforced tape (fig. 4) - Pneumatically controlled cutting device - Adjustable pressure rubber rollers to press the gummed paper onto the boxes - Final long brush for additional pressure on the box surface for a perfect adhesion - Electric cabinet with Siemens PLC S7 1200 model - Kite colour panel touch screen P07 model, 7” - Safety protections as per CE norms In-line machine can be combined to the automatic centering device DAC670 (fig. 6) either centering & measuring device DCM670 (fig. 5) Machine versions: GEM BX670GP – only bottom sealing for box max W & H 670 mm GEM X820GP - box max W & H 820mm, top & bottom sealing OPTIONALS • Tape roll end indicator • Tape application control • Water level indicator • Audio - visual alarms • Boxes counter • Top & bottom sealing disabling
