Capacitive level switch max. 120 °C, 25 bar | LCSO

electro-opticalfor liquidsfor the food industry

The operation of COMECOs level probe LCSO is based on the changing of light reflection when liquid covers an optical sensor, mounted on the top of the probe. This model can be used as a single level switch for sensing presence or absence of liquid. It is applicable for the most of the low-viscose industrial liquids as well as the liquids in food industry, thanks to its stainless steel casing and polysulphone light sensor. The LCSO switch can be equipped with either transistor output, or contact relay output, and the power supply voltage can vary from 12 to 24 VAC/DC, providing convenient application. Two variants are available according to the electrical connection: connector-type (for side mounting) and cable-type (for side mounting and submersible usage). Thanks to its operating principle, power output, and low price, LCSO can be very useful in applications where float and conductive sensors are not applicable and capacitive or pressure sensors are too expensive.
