Stainless steel wire rope HFW2

flexible

Mod. HFW2 .02 Antenna Litz-wire is a flexible stranded antenna-wire The best wire for antennas – quad, delta loop, dipole, wire beam, long-wire, HF receiving antenna, beverage, wire log-periodic, V beam, rhombic Specification – Ø 3.0 mm ( 0.115 Inch ) PVC Jacket UV resistant – Ø 2.1 mm ( 0.083 Inch ) Silver plated copper braid ( 19 steps ) – Ø 1.5 mm ( 0.059 Inch ) 49 x 0.18 stainless steel core AISI 316 ( UNI X 8 CrNiMo 1712 – UNI 6900/71 ) – Up to 12 KW RF, 1.5 to 30 MHz – Temperature range: – 100 to + 155 deg C – Weight: 21.85 g/m – DC resistance: 30 Ohms/Km – RAL 7001 – Breaking load 1170 N ( 257 lbs )
