Unmanaged switch RocketLinx® ES7105

4 portsgigabit EthernetDIN rail mounted

RocketLinx® ES7105Unmanaged Power over Ethernet Industrial switch, four PoE ports and one Fast Ethernet port, IEEE 802.3af compliant. This rugged 4 Port PoE Switch is built for harsh conditions and will operate from -20° to 70° Centigrade (-4° to 158°Fahrenheit).Part Number: 32045-6 Perfect solution for powering IP camera and wireless access points Four 10/100BASE-TX ports with embedded PoE injector and one 10/100BASE-TX uplink port 15.4W full power delivery per port Relay alarm for port failure Terminal block power input for industrial applications DC power jack input for external power adapter End-point PoE architecture DIN rail/wall-mounting and desktop installation Aluminum rugged enclosure with IP31 grade protection Wide operating temperature range (-20° to 70° C) Plug-and-play compact switch RoHS 2 compliant under CE Pepperl+Fuchs Comtrol’s RocketLinx ES7105 is an IEEE 802.3af compliant 4 Port PoE switch designed for a wide range of industrial PoE applications such as IP surveillance cameras, wireless access point, VoIP phone set, POS system, industrial sensors, controllers and security card readers, where a power source is not conveniently located. The RocketLinx ES7105 is equipped with 4 PoE injector switch ports, with each port delivering power up to 15.4 watts, and one 10/100BASE-TX uplink port transferring data to the central network. The RocketLinx ES7105 is compliant to the IEEE 802.3af Power over Ethernet (PoE) standard. The Power Over Ethernet technology can power up PoE enabled powered devices in full capability.
