Unmanaged switch RocketLinx ® ES7110-VB

10 portsgigabitwireless

RocketLinx ® ES7110-VBUnmanaged Power over Ethernet Industrial switch with voltage boost, eight IEEE 802.3af PoE ports and two Gigabit ports.Part Number: 32049-4 Industrial PoE Plus unmanaged switch with Eight 10/100BASE-TX PoE injector ports and two Gigabit uplink ports Plug-and-play rugged PoE switch Voltage boost technology that supports 8-32VDC power input sources for transportation, security and industrial applications IEEE 802.3af compliant PoE with a total output power budget of 65W (15.4W maximum on each port) QoS support for optimizing video and VoIP stream Extended operating temperature range (-25°C to +60°C) Alarm Relay for failure and event notification Industrial-grade aluminum IP30 housing DIN rail/wall-mount installation The RocketLinx ES7110-VB is an IEEE 802.3af compliant PoE switch designed for connecting a wide range of industrial PoE equipment such as IP surveillance cameras, wireless access points, point-of-sale systems, and other devices utilizing 12/24V vehicle power sources or 24V standard industrial power. The RocketLinx ES7110-VB is equipped with eight 10/100BASE-TX PoE injector switch ports, with each port delivering power up to 15.4W, and two 10/100/1000BASE-TX (Gigabit) Ethernet uplink ports for transferring data to the network. The ES7110-VB supports QoS, which ensures high quality video traffic transmission by adjusting the data transfer priority.
