Inductive proximity sensor DW-AV-703-C23-693cylindricalM12PNP
Add to favorites
Compare this product
Characteristics
- Technology
- inductive
- Shape
- cylindrical
- Diameter
- M12
- Output signal
- PNP, IO-Link
- Supply voltage
- 24 Vdc, 12 Vdc, 15VDC
- Material
- stainless steel
- Protection level
- IP68, IP69K
- Other characteristics
- 3-wire
- Length
8 mm
(0.31 in)- Measuring range
7 mm
(0.28 in)- Process temperature
Min.: -25 °C
(-13 °F)Max.: 85 °C
(185 °F)
Description
Switching frequency max. - 15 Hz
Operating pressure [bar] - ≤ 150 bar
Output - Normally Open (NO)
Housing size [mm] - 32 x 20 (C23)
Mounting - Embeddable
