Air filter-regulator Type 330
liquidpressureindustrial

air filter-regulator
air filter-regulator
air filter-regulator
air filter-regulator
air filter-regulator
Add to favorites
Compare this product


Characteristics

Designed for
air, liquid
Filtration method
pressure
Applications
industrial
Fluid specification
condensate
Other characteristics
compact, automatic
Operating pressure

Min.: 0 bar
(0 psi)

Max.: 8 bar
(116.03 psi)

Filtration size

5 µm, 40 µm

Fluid temperature

Min.: -52 °C
(-61.6 °F)

Max.: 90 °C
(194 °F)

Description

The Type 330 Instrument Air Filter Regulator is designed to provide clean, accurate air pressure to instruments, valves, and other automatic control equipment in a lightweight, compact housing. This quality instrument is constructed of durable materials that will provide long lasting corrosion resistance in harsh industrial environments. The Type 330 AFR features either a 40-micron or 5-micron filter to allow for more precise filtration. The Type 330 Filter Regulator with Automatic Drain automatically flushes out condensate waste liquid when a change in air flow occurs or when the supply pressure is reduced. The low maintenance Automatic Drain helps prolong the life of the regulator and filter by preventing corrosion on the bottom of regulator and reducing the load of the filter. Options and features (see specification tab for full list): 40 or 5 micron filter Auto-drain capabilities Low temperature option: down to -62°F
