Semi-automatic filling machine F400X

bottlevialliquids

F400X – Tabletop filler is perfect for low production rates with high accuracy requirements. Fills aqueous solutions to light oils. This product is shipped fully assembled and ready to use. Can fill up to 50 containers a minute, depending on the operator, with accuracy of ± .5%. The Cozzoli F400X-SS (stainless steel) single piston filler is ideal for filling liquids at low production rates with high accuracy. The patented slide valve allows this machine to dispense a wide range of liquids from aqueous solutions to light oils. It is designed for rapid changeover and the positive slide valve action allows the product to be supplied under positive head pressure, allowing overhead or remote supply tank location. • Drive Assembly • Filling Assembly • Stainless Steel Syringe • Stainless Steel Filling Nozzles • (Quantity 6, 6-16 Gauge) • Foot Switch Operation • Stainless Steel Exterior • 316L Stainless Steel Liquid Contact Parts • Tygon Plastic Delivery & Intake Lines • 100-240V, 50/60 Hz, 1Ph Utilities • Operation and Maintenance Manual OPTIONS • Additional Stainless Steel Syringes • Nozzle Holder Assembly • Stainless Steel Valve Assembly • Tygon Intake Line • Delivery Line • Valve Outboard Support C/W Thumb Screw • Stainless Steel Hopper Assembly • Moyno Pump for Filling Viscous Products • Fine Adjustment Volume Control Stop • Mobile Filling • Single Cycle Control • Thermostat Heating Subassembly • Jack Shaft Drive Subassembly • Nozzle Elevating Subassembly • Spare Parts Kit • IQ/OQ Validation Protocol • Factory Acceptance Test Protocol • Performance Qualification Protocol
