Rotary screw capping machine CM series

automaticfor vialsfor the pharmaceutical industry

This high speed rotary crimping machine handles stoppered containers with absolute control while it automatically caps and crimp seals aluminum closures at speeds of up to 200 or 400 containers a minute. As capped containers index into position individual triple-roller crimping heads lower and tuck the skirt under with a gentle progressive roll, then raise as finished containers index out. Uniquely designed, the CM Series is capable of speeds of 200 up to 400 per minute and has the ability to test and record the seal pressure of every closure. Automatic vial height adjustment is provided for easy operator changeover and also is a safeguard against adjustment errors. The CM Series comes standard with a stainless steel exterior and is equipped with a vibratory bowl, conveyor, three star-wheels and a keypad entry message center. Both accommodate tear and flip-off closures as well as line seals ranging from 13 mm - 32 mm, and handle container sizes from 2 ml - 500 ml. These units offer a detection feature that can recognize a “no stopper/no crimp” condition. Also, in the event a crimp takes place on an unstoppered container, as an option, it can be rejected. Notable features include automatic container height adjustment that not only reduces changeover time, but also safeguards against adjustment errors. FEATURES •Continuous motion operation •Sealing pressure set and controlled by crimping head adaptor --eliminating time consuming pressure adjustments •Automatic container height adjustment reduces changeover time •Some crimping heads accept neck finishes 13 mm - 32mm--with every chang-ing cap seats and rollers
