Centerless grinding machine MICRA 10 INTEGRAL
drill bittooloptical

centerless grinding machine
centerless grinding machine
centerless grinding machine
centerless grinding machine
centerless grinding machine
centerless grinding machine
centerless grinding machine
centerless grinding machine
centerless grinding machine
Add to favorites
Compare this product


Characteristics

Type
centerless
Applications
drill bit, optical
Control type
automatic
Other characteristics
precision
Spindle speed

7,100 rpm
(44,611 rad.min-1)

Power

0.2 kW
(0.27 hp)

Description

Negative and positive web thinning Sharpening capacity from mm. 0,5 to 16 mm (with option up to 20 mm.) Rapid, precise, self-centering in 3+3 rakes Accessories supplied include: 16x optical projector with LED LIGHT , two precision spindles to clamp the drill, 10 collets, halogen lamp, 4 grinding wheels, etc. Technical Data: Diameter range mm. 0,5 - 20 Left or right cutting edges 2 - 3 Web thinning negative and positive Point angle 80° - 180° Cutting angle adjustment 0° - 18° Drill length unlimited Spindle motor power 0,18 KW Motor rotation anticlockwise Grinding wheel spindle speed 7100 rpm Dimension grinding wheel Ø 70 x 30 x 25 Overall dimensions: mm 680 x 500 x 520 Weight: KG. 57

VIDEO
