Diesel forklift D20G PLUS
LPGride-onindustrial

Diesel forklift - D20G PLUS - Daewoo Industrial Vehicles - LPG / ride-on / industrial
Diesel forklift - D20G PLUS - Daewoo Industrial Vehicles - LPG / ride-on / industrial
Diesel forklift - D20G PLUS - Daewoo Industrial Vehicles - LPG / ride-on / industrial - image - 2
Diesel forklift - D20G PLUS - Daewoo Industrial Vehicles - LPG / ride-on / industrial - image - 3
Add to favorites
Compare this product


Characteristics

Motor type
diesel, LPG
Operator
ride-on
Applications
industrial, for warehouse, outdoor
Other characteristics
4-wheel, pneumatic tire, heavy-duty, high-performance
Carrying capacity

2,000 kg, 2,500 kg, 3,000 kg
(4,409.2 lb, 5,511.6 lb, 6,613.9 lb)

Overall width

1,165 mm, 1,228 mm
(45.9 in, 48.3 in)

Load center distance

500 mm
(19.7 in)

Height to top of overhead guard

2,143 mm, 2,160 mm
(84.4 in, 85 in)

Length to fork face

2,520 mm, 2,585 mm, 2,687 mm
(99.2 in, 101.8 in, 105.8 in)

Turning circle radius

2,250 mm, 2,300 mm, 2,430 mm
(88.6 in, 90.6 in, 95.7 in)

Travel speed

18 km/h, 19 km/h
(11.2 mph, 11.8 mph)

Lifting speed

490 mm/s, 500 mm/s, 510 mm/s

Rated output

34,200 W, 48,900 W, 51,500 W
(46.5 hp, 66.5 hp, 70 hp)

Rated speed

2,200 rpm, 2,600 rpm
(13,823 rad.min-1, 16,336.3 rad.min-1)

Cubic capacity

2,351 cm³, 3,053 cm³
(79.5 US fl oz, 103.2 US fl oz)

Description

Power, excellent performance, driving comfort, durability, and outstanding fuel efficiency will certainly satisfy you. Main Features • - High powered and fuel efficient Diesel and LPG • - Non asbestos Shoe Brakes • - 1 Speed powershift transaxle for heavy-duty application • - Lift and Tilt Locking Hydraulic Control Valve • - Enhanced maintenance and Serviceability • - OSS(Operator Sensing System) o - No truck moving with an operator’s absence on driver seat o - Hydraulic lifting and lowering locking o - Parking Brake warning o - Seat Belt Indicator • - Available Emission Regulation o - Diesel : EU Stage IIIA o - LPG : Non Certification / EPA Tier Ⅲ Product Concepts The GX Plus Series provides economic benefit without compromising the Performance, Productivity and also Product Quality. All engineering, manufacturing and quality process and system are Supported by Doosan’s headquarter in Korea. Doosan Corporation Industrial Vehicle GX Plus Series, D(G)25G Plus are designed for a broad spectrum of applications in manufacturing, warehousing, outdoor storage and distribution. Whether loading stacks, packing racks or stuffing trucks, D(G)25G Plus are guaranteed to impress both operators and operation’s personnel with its power, performance and productivity
