Starter kit DP-SK-5-200

The xtremeDB StarterKit includes our CANopen output module with 16 outputs as well as cordsets in 5 m length and accessories. With this StarterKit you can practically try out the input module on your desk with a CAN controller and mount it on your machine in a further step. Simply plug it together and put it into operation for series use. Suitable For: - CCpilot V1200, xtremeDBmini, CCpilot V700, CCpilot V1000 Product Family: - xtremeDB Outputs: - 16 Port Number: - 8 Interfaces: - CAN Connection: - DT-4, DT-18, DT / AT / similar Protocol: - CANopen, CAN Layer 2-B Baudrate: - 250, 500 kbit/s Output Signal Type: - DO [4 A], DO [10 A] Auxiliary Voltage: - 12 / 24 V Housing Material: - plastic Operating Temperature: - -40°C ... +80°C IP Rating: - IP67, IP68, IP69K Mounting system: - 2x 6 mm round hole + 1x slotted hole Standards / Approvals: - EN ISO 13766-1, EN ISO 13766-2, ISO 13309
