Temperature converter DSCP55

powerfor RTD sensorsDIN rail

Each DSCP55 RTD Loop-Powered Converter provides a single channel of RTD input which is amplified, linearized and converted to a highlevel 4 to 20mA or 20 to 4mA output. Inputs may be connected by 2, 3, or 4 wires and measurement range may be configured by dip-switch. RTD Input : Pt100 and Ni100 2-, 3- or 4-wire Current Output : 4 to 20mA or 20 to 4mA Loop Powered (5 to 30V DC) Better than ±0.1% Accuracy 14-Bit Resolution Output Overcurrent Protection 500mW Maximum Power Consumption Dip-Switch Configuration Cage Clamp Connectors Hot Swappable Expandable Power-Bus Connector on DIN Rail Guide Compact 93.1 x 6.2 x 102.5mm PBT Black Case Wide Operating Temperature Range : -20°C to 65°C CE Compliant RoHS Directive 2002/95/EC
