Switching power supply PWR-PS5R120W
AC/DCsingle-outputwith short-circuit protection

Switching power supply - PWR-PS5R120W - Dataforth Corporation - AC/DC / single-output / with short-circuit protection
Switching power supply - PWR-PS5R120W - Dataforth Corporation - AC/DC / single-output / with short-circuit protection
Add to favorites
Compare this product


Characteristics

Type
AC/DC
Output
single-output
Technology
switching
Protection
with short-circuit protection, with overload protection, with overcurrent protection, with overheating protection
Mounting
DIN rail
Certifications
CE, TUV
Features
compact
Applications
rugged
Input voltage

Max.: 264 V

Min.: 85 V

Output voltage

24 V

Current

5 A

Power

120 W

Description

Power Supply, DIN Rail Mount, 85-264 VAC 47-63 Hz In, 24 VDC 5.0 A Out Dataforth’s PWR-PS5RxW series sets new standards for switching power supply technology. Combining rugged, compact enclosures, incorporating all international standards and approvals, and offering customers a broad selection of inputs and outputs, the PWR-PS5RxW series makes your power supply choice a simple one. The PWR-PS5RxW series is UL/cUL and TUV Approved, CE Compliant, and UL 508 Listed. Models are available with output ratings from 7.5W to 120W with 24VDC output voltages. Customers may choose from a wide range of input voltages (85 to 264VAC, and 100 to 370VDC compatible), making the PWR-PS5RxW series an unbeatable package of versatility. FEATURES • Universal AC Input (85 to 264VAC) • DC-compatible Input (100 to 370VDC) • Unique Spring-up Terminals • DIN-rail or Panel Mount • Five Different Output Capacities: 7.5W to 120W • UL/cUL, and TUV Approvals • CE Compliant, UL 508 Listed • Certified to EN60950-1 • IP20 Protection (EN60529) • Compliant with EMC Directive EN61204-3 • Manufactured per RoHS III Directive 2015/863
