Analog output module DAT10024

Modbus RTUModbusRS-485

The device DAT10024 drives up to 4 voltage signals up to 10V or current up to 20mA connected both in active and passive loop in digital format. The data are transmitted with MODBUS RTU / MODBUS ASCII protocol over the RS-485 network. To ensure the plant safety, a Watch-Dog timer alarm is provided. The isolation between all of the parts of circuit removes eventual ground-loop effects, allowing the use of the device even in the heavy environmental conditions. The device is housed in a 6 module DIN rough self-extinguishing plastic box for mounting on EN-50022 standard DIN rail.
