Lifting shackle with charging cell 100T

100T REMOTE HYDRAULIC RELEASE LIFTING SHACKLE The Dawson 100 ton release shackle has been specifically designed for use on large tubes, and when used as a pair, tubes weighing up to 200 tons can be lifted. The pin size is 130mm Diameter and is retracted and engaged hydraulically with a hand pump mounted on the ground complete with spooler to keep the hose under control. The hose length is 60mts allowing long piles to be positioned; because the pin is released hydraulically the operator does not need to be directly underneath the shackle. The shackle and spooler are mounted into a fabricated frame so that loading and unloading or moving around the job site is just a single crane lift. FEATURES High strength cast steel body. Pin and hydraulic ram are easily removed for easy maintenance. Main body tested to 5 times SWL Each shackle is proof tested to 2 times SWL Hydraulic pin release.
