Temperature and humidity data logger RN172plus

WiFiModbuswith LCD display

Sensor data measured with UA, where do you want to send it? Various USB type UA sensors can be attached and detached UA1X: temperature and humidity, high temperature, low temperature, ultra low temperature UA2X: 4-20mA, 0-20mA, 0-1V UA5X: Gas sensors (VOC, O2, CO2, CO, SO2, NO2, NH3, H2S, EO, H2) WiFi IEEE 802.11 b,g Data transmission through HTTP, MODBUS TCP, Telnet Front 2-channel LED display / built-in buzzer Easy sensor calibration and replacement by attaching and detaching USB · Cloud-based text transmission, phone transmission, and email report transmission · Radionode365 Cloud Serivce monitoring service support · Tapaculo Lite PC type software support Replaceable sensor support RN172plus product is a data transmitter developed to easily build a sensor monitoring system using a general-purpose communication network. In order to support various sensors, the sensor part is in the form of a USB and has been developed for the user to select. Popular IoT, digital data transmission The physical communication method supports WiFi, and WiFi-ENT with high security level is also supported. In addition, by supporting various protocols such as MODBUS-TCP, HTTP, Telnet, etc., it is possible to construct a sensor monitoring system very conveniently even in a facility with a universal network.
