Spray nozzle WDB seriesfull-conestainless steelbrass
Add to favorites
Compare this product
Characteristics
- Function
- spray
- Stream
- full-cone
- Material
- stainless steel, brass
- Other characteristics
- male, female
- Orifice diameter
Max.: 1.78 mm
(0.07 in)Min.: 0.21 mm
(0.008 in)
Description
SPRAY CHARACTERISTICS
Finely atomized solid cone spray pattern.
Available spray angles of 30°, 45°, 60°, 70°, 80° and 90°.
CONSTRUCTION AND MATERIALS
Nozzle consists of 5 basic parts:
Nozzle body - Brass or 416 Stainless Steel.
Orifice disc - 416 Stainless Steel.
Distributor - 416 Stainless Steel.
Retainer - Brass or 416 Stainless Steel.
Strainer - (used up to WDB 14).
Nozzle thread is 9/16" - 24 UNEF.
Adaptors are available with 1/4" Male BSPT and 1/8"/ 1/4" Female BSPP and can be ordered separately.
ORDER EXAMPLE
WDB 6.0-80° Stainless Steel = Tip Only.
1/4" Female WDB 12,0-60° Stainless Steel = Complete Assembly.
Maximum Recommended Pressure: 35 Bar.G.
